FIG.430A REAR SUSPENSION

FIG.430A REAR SUSPENSION
No No. Part Description Qty Price Per Pcs Remarks
1 41312M68P00-000 SEAT, RR SPRING LWR 2 Rp11.500
2 41341M68P00-000 SEAT, RR SPRING UPR 2 Rp27.000
3 46223M72R00-000 BOLT, RR TRAILING 2 Rp135.500
4 46500M55R30-000 BEAM ASSY, REAR SPNSN 1 Rp5.554.500
5 41311M68P40-000 SPRING, RR COIL 2 Rp367.500
6 41800M68P30-000 ABSORBER ASSY, RR SHOCK 2 Rp1.024.000
7 41821M55R00-000 BOLT, RR SHK ABSORBER LWR 2 Rp33.000
8 41951M68P00-000 CAP, RR SHOCK ABSORBER 2 Rp24.000
9 43402M55R02-000
SUB: 43402M55R01-000		 HUB ASSY, RR WHEEL 2 Rp1.661.000
10 43423M62S00-000
SUB: 43423M79G00-000		 .BOLT, HUB 8 Rp19.000
11 43413M68P00-000 BOLT, REAR HUB MOUNTING 8 Rp17.500
12 43511M68P70-000 DRUM, BRAKE RR 2 Rp655.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
