FIG.500B BRAKE MASTER CYLINDER (4AT)

FIG.500B BRAKE MASTER CYLINDER (4AT)
No No. Part Description Qty Price Per Pcs Remarks
1 51100M68PE1-000 CYLINDER ASSY, BRAKE MASTER 1 Rp1.859.000
2 51200M68P00-000 .RESERVOIR ASSY, MASTER CYLINDER 1 Rp427.500
3 51220M55R00-000 .CAP, RESERVOIR 1 Rp25.000
4 51232M74L00-000 .GROMMET, RSVR CONNECTOR 2 Rp37.500
5 51233M65J00-000 .PIN 1 Rp29.500
6 51240M67LA0-000 .FILTER 1 Rp51.500
7 51311M68K00-000 .O RING 1 Rp10.500
8 51300M50RE0-000 BOOSTER ASSY, BRAKE MASTER 1 Rp1.546.000
9 08361-1508A-000 NUT 2 Rp20.500
10 51120M60M00-000 PIN, BRAKE MASTER CYLINDER 1 Rp10.500
11 51132M79G10-000
SUB: 51132M79G00-000		 PACKING, BRAKE MASTER CYLINDER 1 Rp5.500
12 09159-08127-000 NUT 4 Rp11.000
13 09385M08L01-000 PIN 1 Rp9.000
14-1 51010M68P00-000 HOSE, VACUUM BSTR TO PIPE 1 Rp48.000
14-2 51811M68P00-000 HOSE, VACUUM BSTR TO PIPE 1 Rp40.000 FROM 2016-12
14 51811M68P10-000 HOSE, VACUUM BSTR TO PIPE 1 Rp27.500
15 51020M68P10-000 HOSE, VACUUM PIPE TO INTK 1 Rp24.500
16 51870M68P01-000 PIPE, BRAKE VACUUM 1 Rp56.000
17 09401M15422-000 CLIP 4 Rp9.000
18 08316-1006A-000 NUT 2 Rp2.000

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
