Preview Engine Transmission Electrical Suspension Body

No	No. Part	Description	Qty	Price Per Pcs	Remarks
1	27300-776M0-000 SUB: 27300B776M0N000	GEAR ASSY, DIFFERENTIAL	1	Rp28.771.000
2	27466-775M0-000	.BEARING, DIFF SIDE	2	Rp329.500
3	27317-775M0-000	.BEARING, DRIVE PINION FR	1	Rp485.000
4	27314-775M0-000	.BEARING, DRIVE PINION RR	1	Rp590.000
5	27450-775M0-000	.CARRIER, DIFF	1	Rp7.642.500
6	27458-775M0-000	..WASHER	4	Rp13.500
7	27459-776M0-000	..BOLT	4	Rp32.000
8	27411-775M0-000	.CASE, DIFF	1	Rp7.004.500
9	27111-776M1-000 SUB: 27111-776M0-000	.FLANGE, DIFF	1	Rp1.498.000
10	27310-776M0-000	.GEAR KIT, FINAL DRIVE	1	Rp11.516.000
11	27319-775M0-000	..NUT	1	Rp58.500
12	27330-775M0-000	.GEAR SET, DIFF	1	Rp3.865.000
13	27468-775M0-000 SUB: 27468-775M0L000	.SEAL, DRIVE PINION OIL	1	Rp105.000
14	27461-775M0-000	.NUT	2	Rp203.500
15	27455-775M0-000	.PLATE, DIFF SIDE	2	Rp81.000
16	27456-775M0-000	.PLATE, DIFF SIDE	2	Rp84.500
17	27350-775M0-000	.SHAFT KIT, DIFF PINION	1	Rp713.500
18	27353-775M0-000	..PIN	1	Rp28.500
19	27316-775M0-000	.SHIM SET, DRIVE PINION FR	1	Rp417.000
20	27312-775M0-000	.SHIM SET, DRIVE PINION RR	1	Rp609.500
21-1	27315-775M0-046	.SPACER, PINION BEARING	1	Rp154.500	L:46.67
21-2	27315-775M0-047	.SPACER, PINION BEARING	1	Rp149.500	L:47.01
22	27333-775M0-000	.SPACER SET, DIFF	2	Rp1.131.500
23	27334-775M0-000	.WASHER	2	Rp57.000
24	27318-775M0-000	.WASHER	1	Rp43.000
25	27467-775M0-000	.BOLT	2	Rp18.500
26	27416-775M0-000	.BOLT	10	Rp36.000
27	27302-775M0-000	NUT	10	Rp15.000
28	27303-775M0-000	WASHER	10	Rp13.500
