FUTURA SL415

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG.21 CLUTCHFIG.22 TRANSMISSIONFIG.23 GEAR SHIFT FORKFIG.24 TRANSMISSION CASEFIG.25 GEAR SHIFT CONTROLFIG.26 PROPELLER SHAFTFIG.27 DIFFERENTIAL GEAR

FIG.22 TRANSMISSION

FIG.22 TRANSMISSION
No No. Part Description Qty Price Per Pcs Remarks
1 24110-77500-000 SHAFT, INPUT 1 Rp2.484.000
2 09263-20056-000 BEARING 1 Rp102.000
3 09262-28005-000 BEARING 1 Rp409.000
4 09380-68001-000 SNAP RING 1 Rp38.500
5 09380-28007-000 CIRCLIP 1 Rp24.500
6 09283-25088-000 OIL SEAL 1 Rp60.000
7 24121-85252-000 SHAFT, MAIN 1 Rp1.771.500
8 06111-06004-000
SUB: 06111B06003N000		 BALL 3 Rp1.000
9 09166-30007-000 WASHER 2 Rp91.500
10 DISCONTINUE
SUB: 24211-77320-000		 GEAR, MAINSHAFT LOW 1 -
11 09300-30003-000 BUSH 1 Rp115.000
12 09263-35015-000 BEARING 1 Rp120.000
13 24220-60A01-000 GEAR, MAINSHAFT 2ND 1 Rp1.706.500
14 09263-35015-000 BEARING 1 Rp120.000
15 DISCONTINUE
SUB: 24230-76A20-000		 GEAR, MAINSHAFT 3RD 1 -
16 09263-30031-000 BEARING 1 Rp112.500
17 24250-77501-000 GEAR, MAINSHAFT 5TH 1 Rp1.086.000
18 24255-60A00-000 WASHER 1 Rp72.500
19 24801-60810-000 BEARING 1 Rp208.000
20 09262-30086-000 BEARING 1 Rp369.500
21 09380-62001-000 SNAP RING 1 Rp37.500
22 09262-25073-000 BEARING 1 Rp184.000
23 09380-25011-000 CIRCLIP 1 Rp14.500
24 09380-28007-000 CIRCLIP 2 Rp24.500
25 24131-77502-000
SUB: 24131-77501-000		 SHAFT, COUNTER 1 Rp4.255.000
26 24351-60A10-000 GEAR, COUNTER SHAFT 5TH 1 Rp1.540.500
27 09262-28020-000 BEARING, FRONT 1 Rp197.500
28 09380-28007-000 CIRCLIP 1 Rp24.500
29 09262-28019-000 BEARING, CENTER 1 Rp318.000
30 09380-58001-000 SNAP RING 1 Rp31.500
31 09262-20073-000 BEARING, REAR 1 Rp152.000
32 09380-20011-000 CIRCLIP 1 Rp22.500
33 24400-83002-000 HUB ASSY, SYNCHRONIZER LOW 1 Rp1.388.000
34 24431-83001-000 RING, SYNCHRONIZER LOW 2 Rp632.000
35 09388-00017-000 SPRING, LOW 2 Rp23.000
36 24410-83002-000 HUB ASSY, SYNCHRONIZER HIGH 1 Rp1.124.000
37 24432-60A00-000 RING, SYNCHRONIZER HIGH 3 Rp562.000
38 09388-00019-000 SPRING, HIGH 2 Rp23.000
39 09388-00019-000 SPRING, 5TH SPEED 2 Rp23.000
40 24420-81A23-000 HUB ASSY, REVERSE DRIVE 1 Rp1.147.000
41 24471-60A00-000 KEY 6 Rp19.500
42 24473-70D10-000 KEY 3 Rp29.500
43 24551-77500-000 SHAFT, REVERSE IDLE GEAR 1 Rp424.500
44 06111-06004-000
SUB: 06111B06003N000		 BALL 1 Rp1.000
45 24560-83001-000 GEAR, REVERSE IDLE 1 Rp911.500
46 09166-16018-000 WASHER 1 Rp79.000
47 24571-77500-000 PLATE, SHAFT STOP 1 Rp26.500
48 01570-0820B-000
SUB: 01570-0816A-000		 BOLT 1 Rp31.000
49 24671-77501-000 GEAR, COUNTERSHAFT REVERSE 1 Rp563.500
50 24681-81A42-000
SUB: 24681B81A41N000		 GEAR, MAINSHAFT REVERSE 1 Rp745.500
51 09300-30003-000 BUSH 1 Rp115.000
52 09263-35015-000 BEARING 1 Rp120.000
53 26121-77510-000 GEAR, SPEEDOMETER DRIVE 1 Rp422.500
54 09380-25011-000 CIRCLIP 2 Rp14.500
55 26131-77510-000 GEAR, SPEEDOMETER DRIVEN 1 Rp301.500
56 29431-85400-000 CASE, SPEEDOMETER GEAR 1 Rp111.500
57 09280-19001-000 O RING 1 Rp10.500
58 09280-21014-000 O RING 1 Rp17.000
59 09282-08001-000 OIL SEAL 1 Rp20.500
60 09128-06032-000 BOLT 1 Rp16.500

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
