Preview Engine Transmission Electrical Suspension Body

No	No. Part	Description	Qty	Price Per Pcs
1	22100-77510-000 SUB: 22100-77510L000	COVER ASSY, CLUTCH	1	Rp701.500
2	01550-0816A-000 SUB: 01550B0816AN000	BOLT	6	Rp6.000
3	22400-61J00-000	DISC, CLUTCH	1	Rp665.000
4	23265-77520-000 SUB: 23265B77520N000	BEARING, CLUTCH RELEASE	1	Rp225.000
5	23260-61J00-000	SHAFT, CLUTCH RELEASE	1	Rp117.000
6	09205-03019-000	PIN	1	Rp9.500
7	23264-60A00-000	BUSH	1	Rp84.500
8	23264-60A10-000	BUSH	1	Rp56.000
9	23269-60A00-000	SPRING, RELEASE SHAFT RETURN	1	Rp53.000
10	23266-61J01-000	ARM, CLUTCH RELEASE	1	Rp527.000
11	01550-0835A-000 SUB: 01550B0835AN000	BOLT	1	Rp3.500
12	08322M0108A-000	WASHER	1	Rp5.500
13	08310-0008A-000 SUB: 08310M0008A-000	NUT	1	Rp12.500
14	23710-775A0-000 SUB: 23710B775A0N000	CABLE ASSY, CLUTCH	1	Rp94.500
15	08322-0106A-000 SUB: 08322B0106AN000	WASHER	1	Rp2.500
16	09440-08026-000	SPRING	1	Rp10.500
17	09209-13018-000	PIN	1	Rp23.000
18	09150-06010-000 SUB: 09150B06010N000	NUT	1	Rp4.500
19	DISCONTINUE SUB: 23915-77500-000	CLAMP, CLUTCH CABLE	1	-
20	01550-0612B-000	BOLT	1	Rp16.500
21	DISCONTINUE SUB: 23916-77501-000	CLAMP, CLUTCH CABLE NO.2	1	-
