Ignis MC 2023

Preview Engine Transmission Electrical Suspension Body
< KEMBALI KE THUMBNAIL FIG. 35 ENGINE ELECTRICALFIG. 36 STARTING MOTORFIG. 37 GENERATORFIG. 38 BATTERYFIG. 39 SPEEDOMETERFIG. 40 HEAD LAMP (W/HALOGEN)FIG. 41 HEAD LAMP (W/LED)FIG. 42 FRONTFOG LAMP (W/FRONT FOG LAMP)FIG. 43 REAR LAMPFIG. 44 ROOM LAMPFIG. 45 WIRING HARNESSFIG. 46 ELECTRICAL CONTROL BODYFIG. 47 ELECTRICAL CONTROL INSTRUMENTAL PANELFIG. 48 LOCK SET (GL;5AGS:GLX)FIG. 49 LOCK SET (5MT:GLX)FIG. 50 FRONT WINDOW WIPERFIG. 51 WINDOW WASHERFIG. 52 REAR WINDOW WIPERFIG. 53 AUDIO

FIG. 49 LOCK SET (5MT:GLX)

FIG. 49 LOCK SET (5MT:GLX)
No No. Part Description Qty Price Per Pcs Remarks
1-1 37019M66R11-000 LOCK SET, AUTO STEERING 1 Rp392.000 TYPE-1
1-2 37019M55R90-000 LOCK SET, AUTO STEERING 1 Rp218.000 TYPE-2,TYPE-3
2 37152M75J00-000 .BOLT,STEERING LOCK 1 Rp16.000
3 37145M79M10-000 BLANK KEY 2 Rp301.500
4 37100M68PD0-000
SUB: 37100M68PB1-000		 LOCK ASSY, AUTO STEERING 1 Rp2.313.500
5 37290M68P03-000 SWITCH ASSY, ENGINE START 1 Rp655.500
6-1 37172M68P51-000 REMOCON ASSY, KLS 2 Rp1.242.500 TYPE-1
6-2 37172M50S10-000 REMOCON ASSY, KLS 2 Rp744.500 TYPE-2,TYPE-3

*Harga dapat berubah sewaktu-waktu tanpa pemberitahuan terlebih dahulu.
