| 1 |
24710-68L10-000 |
HOUSING, TORQUE CONVERTOR |
1 |
Rp9.324.000 |
| |
| 2 |
24720-55G10-000 |
CASE, TRANSMISSION |
1 |
Rp17.608.500 |
| |
| 3 |
24725-79C10-000 |
BOLT, T/C HOUSING NO.1 |
12 |
Rp26.500 |
| |
| 4 |
24729-79C10-000 |
BOLT, T/C HOUSING NO.2 |
4 |
Rp32.000 |
| |
| 5 |
24730-55G31-000 |
COVER, T/M REAR |
1 |
Rp3.528.000 |
| |
| 6 |
24732-70H10-000 |
•RING, REAR COVER SEAL |
2 |
Rp75.500 |
| |
| 7 |
24743-57B10-000 |
UNION, OIL PIPE |
2 |
Rp254.500 |
| |
| 8 |
24761-55GT0-000 |
PAN SET, T/M OIL |
1 |
Rp976.500 |
| |
| 9 |
DISCONTINUE
SUB: 24745-59J00-000 |
•MAGNET, OIL CLEANER |
2 |
- |
| |
| 10 |
24781-57B00-000 |
GASKET, DRAIN PLUG |
1 |
Rp33.500 |
| |
| 11 |
24784-79C10-000 |
GASKET, T/M OIL PAN |
1 |
Rp130.000 |
| |
| 12 |
24811-79JT0-000 |
TUBE SET, DIFF SIDE BRG LUB |
1 |
Rp257.000 |
| |
| 13 |
DISCONTINUE
SUB: 24813-55G10-000 |
PLATE, OIL RESERVOIR RH |
1 |
- |
| |
| 14 |
DISCONTINUE
SUB: 24814-79C10-000 |
PLATE, OIL RESERVOIR LH |
1 |
- |
| |
| 15 |
24815-60G10-000 |
GASKET, GOVERNOR APPLY NO.2 |
1 |
Rp74.000 |
| |
| 16 |
24816-60G10-000 |
GASKET, 2ND BRAKE APPLY |
4 |
Rp82.500 |
| |
| 17 |
24818-68J10-000 |
GASKET, GOVERNOR APPLY NO.1 |
1 |
Rp75.000 |
| |
| 18 |
24819-79C10-000 |
GASKET, BRAKE DRUM |
1 |
Rp95.000 |
| |
| 19 |
24821-68L10-000 |
UNION, BREATHER |
1 |
Rp67.000 |
| |
| 20 |
24823-79C10-000 |
PLUG, DRAIN |
1 |
Rp34.000 |
| |
| 21 |
24882-79C10-000 |
BOLT, T/M OIL PAN |
18 |
Rp23.500 |
| |
| 22 |
24884-79C10-000 |
BOLT, T/M REAR COVER |
9 |
Rp36.000 |
| |
| 23 |
24892-79C10-000 |
HARNESS, SOLENOID WIRE |
1 |
Rp1.222.000 |
| |
| 24 |
26449-65G10-000 |
BOLT, OIL DAM PLATE |
1 |
Rp27.500 |
| |
| 25 |
27992-79C10-000 |
O RING, BREATHER PLUG |
1 |
Rp26.500 |
| |
| 26 |
29737-57B00-000 |
O RING, OIL PIPE UNION |
2 |
Rp71.000 |
| |
| 27 |
29738-57B00-000 |
O RING, TRANSMISSION CASE PLUG |
1 |
Rp52.500 |
| |
| 28 |
29738-57B00-000 |
O RING, T/C HOUSING PLUG |
2 |
Rp52.500 |
| |
| 29 |
29738-57B00-000 |
O RING, REAR COVER PLUG |
4 |
Rp52.500 |
| |
| 30 |
DISCONTINUE
SUB: 29849-57B00-000 |
PLUG, TRANSMISSION CASE |
1 |
- |
| |
| 31 |
DISCONTINUE
SUB: 29849-57B00-000 |
PLUG, TORQUE CONVERTER HOUSING |
2 |
- |
| |
| 32 |
DISCONTINUE
SUB: 29849-57B00-000 |
PLUG, T/M REAR COVER |
4 |
- |
| |
| 33 |
29970-57B00-000 |
BOLT, OIL RESERVOIR PLATE |
3 |
Rp83.000 |
| |
| 34 |
29970-57B00-000 |
BOLT, DIFF SIDE BRG LUB TUBE |
1 |
Rp83.000 |
| |
| 35 |
29989-57B00-000 |
BOLT, SOLENOID WIRE HARNESS |
1 |
Rp69.500 |
| |
| 36 |
DISCONTINUE
SUB: 11851-62B00-000 |
HOOK, TRANSMISSION |
1 |
- |
| |
| 37 |
24770-58M10-000 |
TUBE ASSY, T/M OIL FILLER |
1 |
Rp245.500 |
| |
| 38 |
09280-09008-000 |
•O RING (D:2.1,ID:8.8) |
1 |
Rp20.500 |
| |
| 39 |
24825-58M10-000 |
HOSE, T/M BREATHER |
1 |
Rp82.500 |
| |
| 40 |
24830-68L10-000 |
GAUGE ASSY, T/M OIL LEVEL |
1 |
Rp241.500 |
| |
| 41 |
DISCONTINUE
SUB: 24839-63J10-000 |
•EMBLEM, ATF |
1 |
- |
| |
| 42 |
27991-65D01-000 |
PLUG, BREATHER HOSE |
1 |
Rp22.500 |
| |
| 43 |
09403-11320-000 |
CLAMP |
1 |
Rp21.500 |
| |
| 44 |
01421M1035A-000
SUB: 01421-1035A-000 |
STUD BOLT |
1 |
Rp16.000 |
| |
| 45 |
01421-1045A-000 |
STUD BOLT |
1 |
Rp29.500 |
| |
| 46 |
DISCONTINUE
SUB: 01550B0612AN000 |
BOLT |
1 |
- |
| |
| 47 |
01550-0820A-000
SUB: 01550B0820AN000 |
BOLT |
1 |
Rp5.500 |
| |
| 48 |
01550-1040A-000
SUB: 01550B1040AN000 |
BOLT |
1 |
Rp7.000 |
| |
| 49 |
01550-1050A-000 |
BOLT |
4 |
Rp6.000 |
| |
| 50 |
04211M13189-000
SUB: 04211-13149-000 |
PIN |
2 |
Rp9.000 |
| |
| 51 |
08316-1010A-000
SUB: 08316B1010AN000 |
NUT |
2 |
Rp3.500 |
| |
| 52 |
26130-70H11-000 |
GEAR, SPEEDOMETER DRIVEN |
1 |
Rp1.145.000 |
| |
| 53 |
DISCONTINUE
SUB: 26135-79C10-000 |
BOLT, SPEED SENSOR |
1 |
- |
| |
| 54 |
26143-79C10-000 |
SENSOR, SPEED INPUT |
1 |
Rp1.456.000 |
| |
| 55 |
29989-57B00-000 |
BOLT, INPUT SPEED SENSOR |
1 |
Rp69.500 |
| |
